Huawei S5735-L8P4S-A1 (8*10/100/1000BASE-T ports, 4*GE SFP ports, PoE+, AC power)

Heat dissipation mode：	Air cooling heat dissipation and intelligent speed adjustment
Memory：	512 MB
Redundant power supply：	Not supported
Products Status：	New
Maximum input current [A]：	3 A

Heat dissipation mode	Air cooling heat dissipation and intelligent speed adjustment
Memory	512 MB
Redundant power supply	Not supported
Products Status	New
Maximum input current [A]	3 A
USB	Not supported
Power supply mode	AC built-in
Long-term operating altitude [m(ft.)]	0-5000 m (0-16404 ft.)
Chassis height [U]	1
PoE	Supported
PN	98011295
Input voltage range [V]	90 V AC to 290 V AC, 45 Hz to 65 Hz
Eth Management port	Not supported
Availability	>0.99999
RPS input	Not supported
Noise at normal temperature (acoustic pressure) [dB(A)]	30.5 dB(A)
Static power consumption [W]	22.6 W
Number of card slots	0
Model	S5735-L8P4S-A1
MTBF [year]	66.56 year
Dimensions with packaging (H x W x D) [mm(in.)]	110.0 mm x 435.0 mm x 360.0 mm (4.33 in. x 17.13 in. x 14.17 in.)
Number of power slots	0
Weight without packaging [kg(lb)]	2.25 kg (4.96 lb)
RTC	Not supported
Rated input voltage [V]	100 V AC to 240 V AC, 50/60 Hz
Console port	RJ45
Storage altitude [m(ft.)]	0-5000 m (0-16404 ft.)
Certification	EMC certification, Safety certification, Manufacturing certification
Service port surge protection [kV]	Common mode: 7 kV
Long-term operating relative humidity [RH]	5% RH to 95% RH, non-condensing
MTTR [hour]	2 hour
Airflow direction	Air intake from left and front, air exhaustion from right
Maximum heat dissipation [BTU/hour]	Without PoE: 131.71, Full PoE load: 554.81
Wide [mm]	330.0mm
Maximum power consumption [W]	Without PoE: 38.6 W, Full PoE load: 162.6 W (PoE: 124 W)
Flash memory	512 MB
Warranty	1 Year
Typical heat dissipation [BTU/hour]	96.9 BTU/hour
Brand	Huawei
Power supply surge protection [kV]	6 kV in differential mode; 6 kV in common mode
Weight with packaging [kg(lb)]	3.17 kg (6.99 lb)
Height [mm]	43.6 mm
Types of fans	Built-in
Typical power consumption [W]	28.4 W
Long-term operating temperature [C(F)]	C5C to +50C (23F to 122F) at an altitude of 0C1800 m (0C5906 ft.), mapping non-industrial optical modules, C5C to +55C (23F to 131F) at an altitude of 0C1800 m (0C5906 ft.), mapping industrial optical modules with transmission distances less than or equal to 10 km
Storage temperature [C(F)]	C40C to +70C (C40F to +158F)
Noise at normal temperature (acoustic power) [dB(A)]	42.2 dB(A)
Number of fans modules	1
Depth [mm]	220.0mm
