| Brand |
xfusion
|
| Form Factor |
4U
|
| Products Status |
New
|
| Memory |
32 x DIMMs at up to 4800 MT/s, up to 128 GB per DIMM
|
| Chipset |
Emmitsburg PCH
|
| Processor |
2 x 4th Gen Intel Xeon Scalable processors (Sapphire Rapids), up to 350 W TDP per processor
|
| Dimensions (H x W x D) |
175mm x 447 mm x 898mm (6.89 in. x 17.60 in. x 35.35 in.)
|
| Management |
The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening. The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0, provides a remote management user interface based on HTML5/VNC KVM; supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control for simplified management. It is optional to configure the FusionDirector management software that provides advanced management features such as five intelligent technologies, enabling intelligent, automatic, visualized, and refined management throughout the lifecycle.
|
| PCIe Expansion |
Up to 14 x standard PCIe 5.0 slots, including 10 x dedicated slots for GPU cards
|
| Operating Temperature |
5oC to 40oC (41oF to 104oF)*, compliant with ASHRAE Classes A1/A2/A3
|
| RAID |
RAID 0, 1, 10, 5, 50, 6, and 60; supercapacitors for cache data protection against power failures; RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration
|
| Local Storage |
Hot-swappable and flexible drive configurations: Up to 24 x 3.5 SAS/SATA drives Up to 12 x NVMe SSDs and 8 x SATA/SAS drives Flash storage: dual M.2 SSDs
|
| Installation Suite |
L-shaped guide rails, adjustable guide rails, and holding rails
|
| Network |
Multiple network expansion capabilities, 3 x OCP 3.0 NICs
|
| Certifications |
CCC, CQC, VCCI, and CE
|
| OS |
Microsoft Windows Server, SUSE Linux Enterprise Server, Red Hat Enterprise Linux, and Ubuntu
|
| Security |
Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security panel, secure boot, and chassis cover opening detection
|
