$Quote1 Piece(MOQ)
| Brand： | xfusion |
|---|---|
| Form Factor： | 4U |
| Products Status： | New |
| Memory： | 64 x DDR5 DIMMs |
| Chipset： | Emmitsburg PCH |
| Brand | xfusion |
|---|---|
| Form Factor | 4U |
| Products Status | New |
| Memory | 64 x DDR5 DIMMs |
| Chipset | Emmitsburg PCH |
| Dimensions (H x W x D) | Chassis with 2.5 drives: 175 mm x 447 mm x 898 mm (6.89 in. x 17.60 in. x 35.35 in.) |
| Management | The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening. The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0, provides a remote management interface based on HTML5/VNC KVM; supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control for simplified management. It is optional to configure the FusionDirector management software that provides advanced management features such as five intelligent technologies, enabling intelligent, automatic, visualized, and refined management throughout the lifecycle. |
| PCIe Expansion | Up to 22 x PCIe slots, including 1 x FlexIO slot dedicated for the OCP 3.0 NIC and 21 x standard PCIe slots |
| RAID | RAID 0, 1, 10, 1E, 5, 50, 6, or 60; supercapacitors for cache data protection from power failures; RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration |
| Processors | 2 or 4 x 4th Gen Intel Xeon Scalable processors (Sapphire Rapids) with TDP up to 350 W per processor |
| Fan Modules | 8 x hot-swappable counter-rotating fan modules in N+1 redundancy |
| Local Storage | Hot-swappable drive configurations: 8, 24, 25, or 50 x front 2.5 SAS/SATA drives 4 x front 2.5 SAS/SATA drives and 8 x NVMe SSDs 24 x front NVMe SSDs 25 x front 2.5 SAS/SATA drives and 24 x front NVMe SSDs 36 x front E1.S SSDs Up to 52 x 2.5 drives. Flash storage: 2 x M.2 SSDs, supporting hardware RAID |
| Installation Suite | L-shaped guide rails, adjustable guide rails, and holding rails |
| Network | Multiple network expansion capabilities 1 x OCP 3.0 NIC, supporting hot swap |
| OS | FusionOS, Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle, Ubuntu, Debian, and openEuler |
| Certification | CE, UL, CCC, FCC, VCCI, and RoHS |
| Security | Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security panel, secure boot, and chassis cover opening detection |
