$Quote1 Piece(MOQ)
| Brand： | xfusion |
|---|---|
| Form Factor： | 2U |
| Products Status： | New |
| Memory： | 64 x DDR5 DIMMs |
| Chipset： | Emmitsburg PCH |
| Brand | xfusion |
|---|---|
| Form Factor | 2U |
| Products Status | New |
| Memory | 64 x DDR5 DIMMs |
| Chipset | Emmitsburg PCH |
| Dimensions (H x W x D) | Chassis with 2.5 drives: 86.1 mm x 447 mm x 898 mm (3.39 in. x 17.60 in. x 35.35 in.) |
| Management | The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening. The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0, provides a remote management user interface based on HTML5/VNC KVM; supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control for simplified management. It is optional to configure the FusionDirector management software that provides advanced management features such as five intelligent technologies, enabling intelligent, automatic, visualized, and refined management throughout the lifecycle. |
| PCIe Expansion | Up to 10 x PCIe slots, including 1 x FlexIO slot dedicated for the OCP 3.0 NIC and 9 x standard PCIe slots |
| Other Features | |
| RAID | RAID 0, 1, 10, 1E, 5, 50, 6, or 60; supercapacitors for cache data protection from power failures; RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration |
| Processors | 2 or 4 x 4th Gen Intel Xeon Scalable processors with TDP up to 350 W per processor |
| Fan Modules | 6 x hot-swappable counter-rotating fans in N+1 redundancy |
| Local Storage | Hot-swappable drives configurations: 8 x front 2.5 SAS/SATA drives 25 x front 2.5 SAS/SATA drives 4 x front 2.5 SAS/SATA drives and 8 x NVMe SSDs, Flash storage: 2 x M.2 SSDs, supporting hardware RAID |
| Installation Suite | L-shaped guide rails, adjustable guide rails, and holding rails |
| Network | Multiple network expansion capabilities, 1 x OCP 3.0 NIC, supporting hot swap |
| OS | FusionOS, Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, Oracle, Ubuntu, and openEuler |
| Certification | CE, UL, CCC, FCC, VCCI, and RoHS |
| Security | Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security panel, secure boot, and chassis cover opening detection |
