FusionServer 1288H V7

$Quote1 Piece(MOQ) Minimum Order Quantity

Brand：xfusion
Form Factor：1U
Products Status：New
Memory：32 x DDR5 DIMMs, with up to 4800 MT/s speed
Chipset：Emmitsburg PCH
Get Quote
Brand

xfusion
Form Factor

1U
Products Status

New
Memory

32 x DDR5 DIMMs, with up to 4800 MT/s speed
Chipset

Emmitsburg PCH
Processor

1 or 2 x 4th Gen Intel Xeon Scalable processors (Sapphire Rapids) with TDP up to 350 W per processor
Power Supply

2 x hot-swappable PSUs in 1+1 redundancy mode. Supported options include: 900 W AC Platinum/Titanium PSUs (input: 100 V to 240 V AC, or 192 V to 288 V DC), 1500 W AC Platinum PSUs, 1000 W (input: 100 V to 127 V AC), 1500 W (input: 200 V to 240 V AC, or 192 V to 288 V DC), 1500 W 380 V HVDC PSUs (input: 260 V to 400 V DC), 1200 W C48 V to C60 V DC PSUs (input: C38.4 V to C72 V DC), 2000 W AC Platinum PSUs, 1800 W (input: 200 V to 220 V AC or 192 V to 200 V DC), 2000 W (input: 220 V to 240 V AC, or 200 V to 288 V DC)
Management

The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0; provides a remote management user interface based on HTML5/VNC KVM; supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control for simplified management It is optional to configure the FusionDirector management software that provides advanced management features such as five intelligent technologies and realizes intelligent, automated, visualized, and refined management through the lifecycle
PCIe Expansion

Provides 5 x PCIe slots, including 2 x FlexIO slots dedicated for OCP 3.0 NICs and 3 x PCIe slots, and 2 slots support PCIe 5.0
Operating Temperature

5oC to 50oC (41oF to 122oF), compliant with ASHRAE Classes A1, A2, A3, and A4
Other Features
RAID

RAID 0, 1, 10, 1E, 5, 50, 6, or 60; optional supercapacitor for cache data power failure protection, RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration
Local Storage

Supports hot-swappable drives in the following configurations: 10 x 2.5 drives (6C10 NVMe SSDs and 0C4 SAS/SATA drives, with a total number of 10 or less), 10 x 2.5 SAS/SATA drives/SSDs (2C4 NVMe SSDs and 6C8 SAS/SATA drives, with a total number of 10 or less), 10 x 2.5 SAS/SATA drives/SSDs, 8 x 2.5 SAS/SATA drives/SSDs, 4 x 3.5 SAS/SATA drives/SSDs, 32 x E1.S SSDs, 20 x E3.S SSDs*, 2 x M.2 SSDs
Installation Suite

L-shaped guide rails, adjustable guide rails, and holding rails
Network

Provides expansion capability of multiple types of networks, Supports OCP 3.0 NICs. The two FlexIO card slots support two OCP 3.0 NICs, which can be configured as required. Hot swap and PCIe 5.0 are supported
OS

FusionOS, Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle, Ubuntu, Debian, openEuler
Certification

CE, UL, CCC, FCC, VCCI, and RoHS
Security

Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security panel, secure boot, and chassis cover opening detection
